This is highly detailed parts catalog manual. All technical details taken directly from the manufacturer can be found in this manual, It is the factory manual from the manufacturer. Manitou MLT940–120 LSU TURBO Series 3—E2 FORKLIFT parts catalog manual is the same manual used by professional technicians, mechanics and workshops around the world.
Manitou MLT940–120 LSU TURBO Series 3—E2 FORKLIFT parts catalog manual has easy to read text sections with top quality diagrams and instructions, will guide you through fundamentals of maintaining and repairing, step-by-step, to teach you what the factory trained technicians already know by heart. For that reason, you will not find it difficult to repair or to maintain some of the innovative features loaded on the vehicle when you have the manual. Using this repair manual is the true way to keep your vehicle working properly.
Models Cover:
Manitou MLT940–120 LSU TURBO Series 3—E2 FORKLIFT
Manual Covers:
AIR CONDITIONING SYSTEM – 2AA110
[pg. 779]
AIR INTAKE SYSTEM – 4AA313 [pg. 71]
ALTERNATOR INSTALLATION – AP1517
[pg. 481]
BRAKE HYDRAULIC CIRCUIT (1ST
MOUNTING) – 6BA125 [pg. 111]
BRAKE HYDRAULIC CIRCUIT (2ND
MOUNTING) – 6BA203 [pg. 119]
BRAKE LEVER ASSEMBLY (1ST
MOUNTING) – 6BA122 [pg. 109]
BRAKE LEVER INSTALLATION – 6BB91
[pg. 129]
CAB MOUNTING, MISC. – 8AA270 [pg. 153]
CAB, DOOR ASSEMBLY, MISC. – 8AB338
[pg. 179]
CAB, HEATER BLOWER, MISC. I – 8AB772
[pg. 189]
CAB, HEATER BLOWER, MISC. II – 8AB169
[pg. 195]
CAB, INTERNAL COMPONENTS – 8AA269
[pg. 147]
CAB, MISC. COMPONENTS I – 8AB334 [pg.
157]
CAB, MISC. COMPONENTS II – 8AB335 [pg.
163]
CAB, MISC. COMPONENTS III – 8AB336
[pg. 171]
CAMSHAFT, TIMING GEAR – AP1510 [pg.
455]
CRANKSHAFT ASSEMBLY – AP1507 [pg.
441]
CYLINDER ASSEMBLY, BOOM
EXTENDING – 10CC41 [pg. 305]
CYLINDER ASSEMBLY, COMPENSATING –
10CB19 [pg. 301]
CYLINDER ASSEMBLY, LEVELING –
10CF29 [pg. 317]
CYLINDER ASSEMBLY, LH LIFTING –
10CA48 [pg. 293]
CYLINDER ASSEMBLY, RH LIFTING –
10CA123 [pg. 297]
CYLINDER ASSEMBLY, TILTING (1ST
MOUNTING) – 10CD79 [pg. 309]
CYLINDER ASSEMBLY, TILTING (2ND
MOUNTING) – 10CD101 [pg. 313]
DECALS – 12AA298 [pg. 417]
DECALS, CARDS (1ST MOUNTING) –
12AA299 [pg. 421]
DECALS, CARDS (2ND MOUNTING) –
12AA438 [pg. 425]
DRIVE AXLE BRAKE DISC, FRONT (AXLE
244464) – AX1477 [pg. 561]
DRIVE AXLE BRAKE DISC, FRONT (AXLE
246850) – AX1643 [pg. 595]
DRIVE AXLE BRAKE DISC, FRONT (AXLE
255000) – AX1772 [pg. 625]
DRIVE AXLE BRAKE DISC, FRONT (AXLE
256309) – AX1810 [pg. 651]
DRIVE AXLE BRAKE DISC, REAR (AXLE
244449) – AX1488 [pg. 681]
DRIVE AXLE BRAKE DISC, REAR (AXLE
246851) – AX1649 [pg. 711]
DRIVE AXLE BRAKE DISC, REAR (AXLE
255001) – AX1766 [pg. 741]
DRIVE AXLE BRAKE DISC, REAR (AXLE
254999) – AX1816 [pg. 769]
DRIVE AXLE DIFFERENTIAL, FRONT (AXLE
244464) – AX1475 [pg. 547]
DRIVE AXLE DIFFERENTIAL, FRONT (AXLE
246850) – AX1641 [pg. 581]
DRIVE AXLE DIFFERENTIAL, FRONT (AXLE
255000) – AX1770 [pg. 613]
DRIVE AXLE DIFFERENTIAL, FRONT (AXLE
256309) – AX1808 [pg. 639]
DRIVE AXLE DIFFERENTIAL, REAR (AXLE
244449) – AX1486 [pg. 667]
DRIVE AXLE DIFFERENTIAL, REAR (AXLE
246851) – AX1647 [pg. 697]
DRIVE AXLE DIFFERENTIAL, REAR (AXLE
255001) – AX1764 [pg. 729]
DRIVE AXLE DIFFERENTIAL, REAR (AXLE
254999) – AX1814 [pg. 757]
DRIVE AXLE HOUSING, FRONT (AXLE
244464) – AX1474 [pg. 543]
DRIVE AXLE HOUSING, FRONT (AXLE
246850) – AX1640 [pg. 577]
DRIVE AXLE HOUSING, FRONT (AXLE
255000) – AX1769 [pg. 609]
DRIVE AXLE HOUSING, FRONT (AXLE
256309) – AX1807 [pg. 637]
DRIVE AXLE HOUSING, REAR (AXLE
244449) – AX1485 [pg. 663]
DRIVE AXLE HOUSING, REAR (AXLE
246851) – AX1646 [pg. 695]
DRIVE AXLE HOUSING, REAR (AXLE
255001) – AX1763 [pg. 725]
DRIVE AXLE HOUSING, REAR (AXLE
254999) – AX1813 [pg. 753]
DRIVE AXLE PIVOT, FRONT (AXLE 244464)
– AX1479 [pg. 571]
DRIVE AXLE PIVOT, FRONT (AXLE 246850)
– AX1645 [pg. 603]
DRIVE AXLE PIVOT, FRONT (AXLE 255000)
– AX1774 [pg. 631]
DRIVE AXLE PIVOT, FRONT (AXLE 256309)
– AX1812 [pg. 657]
DRIVE AXLE PIVOT, REAR (AXLE 244449)
– AX1490 [pg. 689]
DRIVE AXLE PIVOT, REAR (AXLE 246851)
– AX1651 [pg. 719]
DRIVE AXLE PIVOT, REAR (AXLE 255001)
– AX1768 [pg. 747]
DRIVE AXLE PIVOT, REAR (AXLE 254999)
– AX1818 [pg. 775]
DRIVE AXLE REDUCTION GEAR, FRONT
(AXLE 244464) – AX1476 [pg. 553]
DRIVE AXLE REDUCTION GEAR, FRONT
(AXLE 246850) – AX1642 [pg. 587]
DRIVE AXLE REDUCTION GEAR, FRONT
(AXLE 255000) – AX1771 [pg. 617]
DRIVE AXLE REDUCTION GEAR, FRONT
(AXLE 256309) – AX1809 [pg. 643]
DRIVE AXLE REDUCTION GEAR, REAR
(AXLE 244449) – AX1487 [pg. 673]
DRIVE AXLE REDUCTION GEAR, REAR
(AXLE 246851) – AX1648 [pg. 703]
DRIVE AXLE REDUCTION GEAR, REAR
(AXLE 255001) – AX1765 [pg. 733]
DRIVE AXLE REDUCTION GEAR, REAR
(AXLE 254999) – AX1815 [pg. 761]
DRIVE AXLE STEERING SYSTEM, FRONT
(AXLE 244464) – AX1478 [pg. 567]
DRIVE AXLE STEERING SYSTEM, FRONT
(AXLE 246850) – AX1644 [pg. 599]
DRIVE AXLE STEERING SYSTEM, FRONT
(AXLE 255000) – AX1773 [pg. 629]
DRIVE AXLE STEERING SYSTEM, FRONT
(AXLE 256309) – AX1811 [pg. 655]
DRIVE AXLE STEERING SYSTEM, REAR
(AXLE 244449) – AX1489 [pg. 685]
DRIVE AXLE STEERING SYSTEM, REAR
(AXLE 246851) – AX1650 [pg. 715]
DRIVE AXLE STEERING SYSTEM, REAR
(AXLE 255001) – AX1767 [pg. 745]
DRIVE AXLE STEERING SYSTEM, REAR
(AXLE 254999) – AX1817 [pg. 773]
DRIVE AXLE, FRONT (AXLE 244464) –
AX2529 [pg. 541]
DRIVE AXLE, FRONT (AXLE 246850) –
AX2563 [pg. 575]
DRIVE AXLE, FRONT (AXLE 255000) –
AX2593 [pg. 607]
DRIVE AXLE, FRONT (AXLE 256309) –
AX2605 [pg. 635]
DRIVE AXLE, REAR (AXLE 244449) –
AX2531 [pg. 661]
DRIVE AXLE, REAR (AXLE 246851) –
AX2564 [pg. 693]
DRIVE AXLE, REAR (AXLE 255001) –
AX2591 [pg. 723]
DRIVE AXLE, REAR (AXLE 254999) –
AX2606 [pg. 751]
DRIVESHAFT, FRONT AXLE – BP159 [pg.
535]
DRIVESHAFT, GEARBOX REDUCTION –
BP131 [pg. 533]
DRIVESHAFT, REAR AXLE – BP160 [pg. 537]
ELECTRICAL ASSEMBLIES, MISC. I –
11CB455 [pg. 387]
ELECTRICAL ASSEMBLIES, MISC. II –
11CB490 [pg. 395]
ELECTRICAL, DASHBOARD,
INSTRUMENTS, FWD/REV LEVER –
11CC100 [pg. 403]
ELECTRICAL, ENGINE & TRANSMISSION
SENSORS – 11CD79 [pg. 411]
ELECTRICAL, FUSEBOX – 11CA51 [pg. 383]
ELECTRICAL, IGNITION – 11AA603 [pg. 371]
ELECTRICAL, JOYSTICK CONTROL (1ST
MOUNTING) – 11AA667 [pg. 375]
ELECTRICAL, JOYSTICK CONTROL (2ND
MOUNTING) – 11AA991 [pg. 379]
ELECTRICAL, PRIMARY (1ST MOUNTING) –
11AA602 [pg. 335]
ELECTRICAL, PRIMARY (2ND MOUNTING)
– 11AA987 [pg. 343]
ELECTRICAL, PRIMARY (3RD MOUNTING)
– 11AA988 [pg. 351]
ELECTRICAL, PRIMARY (4TH MOUNTING)
– 11AA989 [pg. 359]
ELECTRICAL, SEAT ACTIVATION –
11AA990 [pg. 367]
ENGINE BLOCK – AP1506 [pg. 437]
ENGINE COMPARTMENT, MISC. I (1ST
MOUNTING) – 9AA173 [pg. 199]
ENGINE COMPARTMENT, MISC. I (2ND
MOUNTING) – 9AA312 [pg. 209]
ENGINE COMPARTMENT, MISC. II –
9AA174 [pg. 219]
ENGINE FAN, PULLEYS – 4AA311 [pg. 59]
ENGINE HEAD ASSEMBLY – AP1508 [pg.
445]
ENGINE HEAD COVER – AP1512 [pg. 465]
ENGINE OIL FILTER HOUSING AND
COOLER – AP1513 [pg. 469]
ENGINE, COMPLETE, MISC. – AP2061 [pg.
429]
ENGINE, MISC. BRACKETS – 11CF6 [pg.
413]
ENGINE, OIL PUMP AND SUMP – AP1511
[pg. 461]
ENGINE, TRANSMISSION MOUNTS –
4AA312 [pg. 65]
EXHAUST MANIFOLD – AP1516 [pg. 479]
EXHAUST SYSTEM – 4AA313 [pg. 71]
FENDERS & MIRROR – 9AA176 [pg. 225]
FILTERS – 2AA92 [pg. 33]
FLYWHEEL – AP1518 [pg. 485]
FRAME LEVELING SYSTEM (1ST
MOUNTING) – 10AG102 [pg. 273]
FRAME LEVELING SYSTEM (2ND
MOUNTING) – 10AG177 [pg. 279]
FRAME MISC., MIRROR – 9AA175 [pg. 221]
FRAME, ASSEMBLY – 6AA246 [pg. 105]
FUEL SYSTEM ASSEMBLY – 4AC135 [pg.
83]
GASKETS, ENGINE – AP1521 [pg. 495]
GEARBOX, REDUCTION – BP110 [pg. 499]
HYDRAULIC BOOM CIRCUIT – 10AE467
[pg. 265]
HYDRAULIC CONTROL LEVER (1ST
MOUNTING) – 10AA415 [pg. 241]
HYDRAULIC CONTROL LEVER (2ND
MOUNTING) – 10AA618 [pg. 247]
HYDRAULIC OIL COOLING – 4AA372 [pg. 77]
HYDRAULICS, BOOM LIFTING – 10AE465
[pg. 255]
HYDRAULICS, COMPENSATION CYLINDER
– 10AE466 [pg. 259]
HYDRAULICS, CONTROL VALVE – 10DA10
[pg. 321]
HYDRAULICS, FILTER ASSEMBLY,
STEERING VALVE – 10EA123 [pg. 331]
HYDRAULICS, PRIMARY – 10AA414 [pg.
231]
HYDRAULICS, STEERING CIRCUIT –
10BA194 [pg. 285]
HYDRAULICS, VALVE BANK ASSEMBLY –
10DA241 [pg. 325]
RADIATOR INSTALLATION (1ST
MOUNTING) – 4AA309 [pg. 41]
RADIATOR INSTALLATION (2ND
MOUNTING) – 4AA576 [pg. 47]
RADIATOR INSTALLATION (3RD
MOUNTING) – 4AA536 [pg. 53]
RADIATOR MISC. – 4AA310 [pg. 55]
ROCKER ARM ASSEMBLY – AP1509 [pg.
451]
SEAT ASSEMBLY & INSTALLATION (1ST
MOUNTING) – 8AA119 [pg. 139]
SEAT ASSEMBLY & INSTALLATION (2ND
MOUNTING) – 8AA379 [pg. 143]
STARTER MOTOR – AP1519 [pg. 489]
TELESCOPIC BOOM – 5BA280 [pg. 93]
TIRES & WHEELS – 3AA172 [pg. 37]
TRANSMISSION AND CONVERTER – BP128
[pg. 509]
TRANSMISSION ASSEMBLY, GEARS –
BP130 [pg. 521]
TRANSMISSION CONTROL VALVE – BP127
[pg. 511]
TRANSMISSION MISC. – BP129 [pg. 513]
TURBO CHARGER ASSEMBLY – AP1520
[pg. 491]
WATER OUTLET, MISC. – AP1514 [pg. 473]
WATER PUMP – AP1515 [pg. 477]
******
============
